116KG Propulsion Drone With 238100 Brushless Motor With 24S 300A Motor Controller 63'' Propeller

Name: 116KG Propulsion Drone With 238100 Brushless Motor With 24S 300A Motor Controller 63 Propeller
Brand: Furious Motor
Price: 3316 USD

Quality 116KG Propulsion Drone With 238100 Brushless Motor With 24S 300A Motor Controller 63'' Propeller wholesale

Brand Name : Furious Motor

Model Number : 238100

Certification : CE

Place of Origin : China

MOQ : 1

Price : $3316

Payment Terms : L/C,D/A,D/P,T/T,Western Union

Supply Ability : 3000 pcs per month

Delivery Time : 5-8 working days

Packaging Details : Carton witn protection (EPE)

Model : 238100

Dimension : 238mm * 100mm

KV : 35

Max. Thrust : 116KG

Max. Torque : 79N.m

Max. RPM : 2881

Suggested ESC : 24S 300A

Suggested Prop : 63 inch propeller

Max. Current : 288A

Max. Voltage : 95V

Max. Power : 27KW

Li - Po : 14S - 24S

Hall Sensor : Optional

Weight : 7.8KG

Application : Drone

Contact Now

Introduction

The Furious Motor 116kg thrust propulsion system is a robust and efficient solution purpose-built for heavy-lift and multi-rotor drones. It is precisely engineered to integrate seamlessly with a 63-inch propeller and a 24S 300A ESC, ensuring smooth operation, reliable control, and optimal power output.

Delivering a maximum thrust of up to 116kg, this high-performance system is perfectly suited for a wide range of demanding applications—including unmanned aerial vehicles, large-scale multi-rotor platforms, and industrial-grade heavy-lift drones. Whether used for cargo transport, inspection, or specialized aerial missions, the Furious Motor 116kg propulsion system offers the strength, stability, and efficiency required to get the job done with confidence.

Tech Specs

System

Max. Thrsut	116 kg / rotor
Takeoff Weight	40 kg - 55 kg / rotor
Suggested ESC	24 S 300 A
Suggested Propeller	63 inch propeller
Suggested Battery	12 S - 24 S
Working Temperature	-20 °C ~ 50 °C
Total Weight	9.4 kg
Application	Multi rotor drone, heavy lift drone

Motor

Model	238-100
KV	35
Max. Thrsut	116 kg
Max. Torque	79 N·m
Max. RPM	2881
Dimension	238 mm * 100 mm
Weight	7.8 kg

ESC

Model	24 S 300 A
Suggested Battery	12 S ~ 24 S (Li-Po)
PMW Signal	3.3 V / 5 V
Pulse Width	900 us ~ 2000 us
Signal Frequency	50 Hz ~ 400 Hz
Max. Input Voltage	DC 50 V ~ 100 V
Max. Input Current	240 A
Weight	812 g
Dimension	140.5 mm * 66.6 mm * 47.1 mm

Propeller

Model	63 inch 2-blade
Diameter	63 inch
Material	Carbon fiber
Weight	820 g

Details

116KG Propulsion Drone With 238100 Brushless Motor With 24S 300A Motor Controller 63'' Propeller

116KG Thrsut Propulsion System With 238100 Brushless Motor With 24S 300A Motor Controller And 63 Inch Propeller
